Description

Product Description:

The Hand-Held Dot Peen Marking Machine Without Display is a highly portable and durable industrial marking solution, designed for flexibility, precision, and ease of use. Unlike models with integrated screens, this variant operates entirely through an external PC or controller. Therefore, it is ideal for users who prefer centralized data entry, advanced layout design, and seamless integration with factory software systems.

Technical Specifications:

• Marking Technology: Pneumatic or Electromagnetic Dot Peen

• Operation Mode: PC-controlled via specialized software

• Marking Area: 75 x 25 mm / 100 x 100 mm / custom sizes available

• Compatible Materials: Mild steel, stainless steel, aluminum, brass, plastic, coated surfaces

• Marking Depth: Adjustable (up to 0.5 mm depending on material)

• Power Supply: 220V AC

• Air Pressure (if pneumatic): 4–6 bar (requires compressor)

• Communication Interface: USB or RS232

• Weight: Lightweight handheld unit (approx. 5–9 kg)

• Software Features: Serial numbers, date/time stamps, QR/2D codes, logos, batch codes

Key Features:

• Fully Portable – Easily mark large or immobile components directly

• Software-Based Control – Allows for custom layout, data automation, and centralized setup

• Precision Marking – Ensures deep, permanent, and readable output

• No Built-in Display – Reduces cost while maintaining high functionality

• Easy to Handle – Works on all orientations: horizontal, vertical, or curved surfaces

• Minimal Maintenance – Simplified design and durable construction ensure longevity

Applications:

This machine is widely used in industries such as:

• Automotive (chassis and engine block marking)

• Heavy machinery and equipment manufacturing

• Structural steel fabrication

• Oil, gas, and pipeline identification

• Railways, shipbuilding, and aerospace sectors
